Features
Performance:
- 216Gbps switch fabric, at least extend to 6*10GE XFP ports.
- Hardware routing, wire-speed L3 switching, packet forwarding rate: 126Mpps.
- Optical fiber supports up to 80 km longdistance transfer, direct connection to MAN backbone networks.
Security and reliability:
- Quota system for connected hosts per port.
- IEEE 802.1x port-based user authentication.
- Ethernet port trunking provides more bandwidth and system redundancy.
- Powerful ACL supports L2-L4 data filtering.
Easy maintenance:
- Supports device stacking through cluster. technology. Central management with unified IP address saves IP addresses.
- Management via CONSOLE port, Web, SNMP, etc.
- BootRom and other software upgrade through TFTP.
- Support DHCP and relay, provide dynamic IP address assignment.
- Support SFP standard interface, protect your investment.
- Redundant power supply.
Powerful traffic and broadcast control:
- Automatically detect and restrain broadcast storm, support IGMP datagram snooping, effectively restrict broadcast flooding.
- Full- and half- duplex traffic control.
- Ethernet port bit rate quota.
- Advanced buffer management supports 802.1p, with 4 dispatching queues per port mapping the 8 priority queues in 802.1p.
- IP multicast and QoS support.
- Jumbo frame.
Multiple routing polices:
- Static routing.
- Support RIP v1/v2, OSPF v2, and many other dynamic routing protocols.
- Support PIM-SM, PIM-DM and many other multicast routing protocols.
